Handling Networking Certificates for Fortigates

How-to guides for networking and network security. Written by a network engineer with 20+ years of IT experience.

Introduction

This is a general overview of how to handle certificate renewals both from CSR creation, and when handed different types of certificate files. Each section will have a type of certificate, and explain how to convert it for use on a Fortigate. I've also included links below for reading. The easiest way is always to generate a CSR (Certificate Signing Request) from the firewall, and sign it from a Certificate Vendor (e.g. GoDaddy, Network Solutions, etc), but you won't always be able to do that.

Generate the CSR

This is by far the easiest way to get a certificate to work on a Fortigate. This has you generate a CSR from the firewall, and sign it via an SSL Certificate Vendor/Authority. We're going to use the WebGUI for this as it's 100x easier, but if you want to do it via CLI then that's fine too.

Log into the Fortigate via WebGUI (e.g. https://192.168.1.99)

Go to System

Go to Certificates

Click Generate

Enter Certificate Name (e.g. sslvpn.thepracticalpacket.com-2026)

Set the Key Type to RSA

Set the Key Size to 2048 Bit

Select the domain name and type in the FQDN (e.g. sslvpn.thepracticalpacket.com)

Fill in the rest of the information as needed (none of it is NEEDED reaslly)

Select the Enrollment Method as File Based

Click OK

To save the .csr file to your drive, highlight the "pending" certificate and select Download

Log into your Certificate Vendor/Authority (e.g. Godaddy)

You can follow the instructions in the links section for vendor specific ways to get CSRs signed

Converting from a .crt + .key to PKCS#12 for Importing

When you aren't able to generate your own private key and get a CSR signed, sometimes you will be provided a certificate file and a private key file. The easiest way to import this is to convert it to an encrypted PKCS12 formatted file using OpenSSL.

Download OpenSSL from the link below (Choose the Win64 OpenSSL v4.0.1 version if you're using Windows and you're not sure)

Prepare to convert by gathering the location of your certificate (.crt) file and your private key file (e.g. c:/Temp/certificate.crt)

Open a Windows Explorer window (Win+E) and go to C:\Program Files\OpenSSL-Win64 (or wherever you installed OpenSSL)

Shift right click on the blank space while inside the folder and choose "Open Powershell here"

For this example, we'll assume the certificate file is named server.crt, and the private key file is named server.key, and the PKCS#12 file you want will be named server.p12

Type the following: .\openssl.exe pkcs12 -export -out server.p12 -inkey server.key -in server.crt

It will ask you for a password. Make sure you use a strong password and document it somewhere safe!

This will import your private key and certificate, and then export it as a PKCS12 formatted file

Applying a PKCS#12/PFX Certificate to the Firewall

Adding a PKCS12 (also known as a PFX) Certificate to a firewall is simple once you have it.

Log into the Fortigate via WebGUI (e.g. https://192.168.1.99)

Go to System

Go to Certificates

Click on Import

Click on Local Certificate

Click on PKCS#12 Certificate

Browse to the PKCS12 formatted file you created or were given

Type the password you created or were given with the file

Click Okay

You are now ready to use this for SSLVPN or anything else you need certificates for
